DM Advantage Two-Speed Reman: 79A9809-2

Order Part

Horton Service # 79A9809-2 Horton OEM # 98A9809

This product can be used as a replacement part for:Caterpillar M6X0886, Paccar F17-1000-329

Replacement Options

DM Advantage Two-Speed Reman

DM Advantage On/Off

DM Advantage On/Off Reman

Item	Description	Qty
1	JOURNAL BRACKET	1
2	SHEAVE BEARING, includes bearing install tool	1
3	SHEAVE	1
4	BEARING NUT	1
5	AIR CHAMBER CAP	1
6	O-RING SEAL	1
9	FAN MOUNTED FRICTION DISC (FMFD)	1
17	BUTTON HEAD SCREWS	8
18	AIR CHAMBER SEAL	1
20	FACE SEAL	1
22	BEARING RETAINING RING	1
23	AIR CARTRIDGE ASSEMBLY	1
24	AIR CARTRIDGE RETAINING RING	1
27	FAN MTG STUD	6
28	FRICTION LINER	1
44	BEARING SPACERS	1
50	CLUTCH PACK - SPRING HOUSING/PISTON	1
60	Magnet Assembly	*

	ITEM 1	ITEM 3	ITEM 44	BEARING KIT	FMFD KIT	HORTON REPAIR KIT	SEAL KIT
Service # 79A9809-2 OEM # 98A9809	18717	18716	no spacer	995550	2S-DP-CP	2S-DP	994346
Service # 79A9809-2 OEM # 98A9809	Repair / Replace
