DM Advantage Two-Speed: 99A9701-2

Order Part

Horton Service # 99A9701-2 Horton OEM # 98A9701, 98A9701-2

This product can be used as a replacement part for:International 4041985C1

Replacement Options

DM Advantage Two-Speed

99A9701-2

DM Advantage On/Off

99A9701

Repair Kits

FAN CLUTCH REPAIR KIT

2S-DP

Additional Repair Kit Options

Part Components

View Full List of Components

Standard Parts List

Item	Description	Qty
1	JOURNAL BRACKET	1
2	SHEAVE BEARING, includes bearing install tool	1
3	SHEAVE	1
4	BEARING NUT	1
5	AIR CHAMBER CAP	1
6	O-RING SEAL	1
9	FAN MOUNTED FRICTION DISC (FMFD)	1
17	BUTTON HEAD SCREWS	8
18	AIR CHAMBER SEAL	1
20	FACE SEAL	1
22	BEARING RETAINING RING	1
23	AIR CARTRIDGE ASSEMBLY	1
24	AIR CARTRIDGE RETAINING RING	1
27	FAN MTG STUD	6
28	FRICTION LINER	1
44	BEARING SPACERS	1
50	CLUTCH PACK - SPRING HOUSING/PISTON	1
60	Magnet Assembly	*

	ITEM 1	ITEM 3	ITEM 44	A - SUPER QUICK KIT	BEARING KIT	FMFD KIT	FRICTION DISC KIT	HORTON REPAIR KIT	POLARFORCE KIT	SEAL KIT	STUD KIT	SUPER KIT
Service # 99A9701-2 OEM # 98A9701	45027	101920	12574	2S-DP	995550	2S-DP-CP	994348	2S-DP	2S-DP	994346	995514	2S-DP
Service # 99A9701-2 OEM # 98A9701	Two Speed version of 99A9701. Similar to 99A9656-2 but with both 8K and 6K set of grooves on Sheave. Repair Kit Part # 995692 can be used to convert 99A9656-2 to 99A9701-2. Part # 99A4728 is the new 8K, 6K Repair / Replace

Notes

Two Speed version of 99A9701. Similar to 99A9656-2 but with both 8K and 6K set of grooves on Sheave. Repair Kit Part # 995692 can be used to convert 99A9656-2 to 99A9701-2. Part # 99A4728 is the new 8K, 6K
