DM Advantage Two-Speed: 99A8624-2

Order Part

Horton Service # 99A8624-2 Horton OEM # 98A8624-2

Clutch Type: DM Advantage Two-Speed

Replacement Options

DM Advantage Two-Speed

Repair Kits

FAN CLUTCH REPAIR KIT

Additional Repair Kit Options

Part Components

View Full List of Components

Standard Parts List

	Item	Description	Qty	Comments
	1	JOURNAL BRACKET	1
	2	SHEAVE BEARING, includes bearing install tool	1
	3	SHEAVE	1
	4	BEARING NUT	1
	5	AIR CHAMBER CAP	1
	6	O-RING SEAL	1
	9	FAN MOUNTED FRICTION DISC (FMFD)	1
	17	BUTTON HEAD SCREWS	8
	18	AIR CHAMBER SEAL	1
	20	FACE SEAL	1
	22	BEARING RETAINING RING	1
	23	AIR CARTRIDGE ASSEMBLY	1
	24	AIR CARTRIDGE RETAINING RING	1
	27	FAN MTG STUD	6
	28	FRICTION LINER	1
	44	BEARING SPACERS	1
	50	CLUTCH PACK - SPRING HOUSING/PISTON	1
	60	Magnet Assembly	*

	ITEM 1	ITEM 3	ITEM 44	BEARING KIT	FMFD KIT	POLARFORCE KIT	SEAL KIT	SUPER KIT
Service # 99A8624-2 OEM # 98A8624-2	19499	19629	no spacer	995550	995591-350	2S-DP-350	994346	see note below
Service # 99A8624-2 OEM # 98A8624-2	Requires 995543-350 Polar Force and 995550 Bearing Kit for complete rebuild. Repair / Replace

Notes

Requires 995543-350 Polar Force and 995550 Bearing Kit for complete rebuild.
