DM Advantage Two-Speed: 99A8255

Order Part

Horton Service # 99A8255 Horton OEM # 98A8255

Clutch Type: DM Advantage Two-Speed

Replacement Options

DM Advantage Two-Speed

Repair Kits

FAN CLUTCH REPAIR KIT

Additional Repair Kit Options

Part Components

View Full List of Components

Standard Parts List

	Item	Description	Qty	Comments
	1	JOURNAL BRACKET	1
	2	SHEAVE BEARING, includes bearing install tool	1
	3	SHEAVE	1
	4	BEARING NUT	1
	5	AIR CHAMBER CAP	1
	6	O-RING SEAL	1
	9	FAN MOUNTED FRICTION DISC (FMFD)	1
	17	BUTTON HEAD SCREWS	8
	18	AIR CHAMBER SEAL	1
	20	FACE SEAL	1
	22	BEARING RETAINING RING	1
	23	AIR CARTRIDGE ASSEMBLY	1
	24	AIR CARTRIDGE RETAINING RING	1
	27	FAN MTG STUD	6
	28	FRICTION LINER	1
	44	BEARING SPACERS	1
	50	CLUTCH PACK - SPRING HOUSING/PISTON	1
	60	Magnet Assembly	*

	ITEM 1	ITEM 3	ITEM 44	BEARING KIT	FMFD KIT	POLARFORCE KIT	SEAL KIT	SUPER KIT
Service # 99A8255 OEM # 98A8255	101946	101947	100738	995566	see note below	2S-DP-250	994346	see note below
Service # 99A8255 OEM # 98A8255	Requires 995543-250 Polar Force Kit and 995566 Bearing Kit for Complete Rebuild.17274 Fan Spacer. Overall Length includes Fan Spacer. Repair / Replace

Notes

Requires 995543-250 Polar Force Kit and 995566 Bearing Kit for Complete Rebuild.17274 Fan Spacer. Overall Length includes Fan Spacer.
